The first computers on the moon

• Margaret Hamilton coined the term software engineering while developing the Apollo Guidance Computer’s (AGC) priority interrupt system, enabling critical real-time error recovery during the lunar descent.
• The 31.8kg AGC pioneered the large-scale use of integrated circuits to meet strict spaceflight miniaturisation requirements
• Hand-threaded core rope memory delivered unprecedented data density, while MIT's simplified IC design ensured zero in-flight hardware failures.

The computer industry was still in its infancy when JFK announced that ‘we choose to go to the moon’ and the sky was no longer the limit. Getting to the moon is hard. Indeed, it is rocket science, which meant computers were essential.

In 1952, a UNIVAC machine predicted Eisenhower would win the US election, taking 82% of the electoral college vote (in the end, he took 83%), and the computer had come of age. However, packing an eight-ton computer, measuring 4.3m by 2.4m by 2.6m, into the Apollo command module (let alone the lunar excursion module) was not going to happen.

NASA used industry-standard IBM mainframes on the ground. In 1968, a year before Apollo 11, they upgraded to an IBM System/360 Model 50, costing $45k per month to rent.

They also purchased an ILLIAC IV supercomputer. Even the mini-computers of the day were too big and bulky for the Apollo mission, but fortunately by the mid-sixties, miniaturisation was well under way with transistors already being replaced by integrated circuits.

Launch vehicle control

The Saturn V launch vehicle was controlled by the Instrumentation Ring, or Instrumentation Unit (IU), located on top of the third stage. It contained all the navigation, guidance, control, and sequencing hardware for the main launch vehicle, using triple redundancy for safety. IBM built this unit in Huntsville, Alabama. This section was approximately six metres in diameter and one metre tall, weighing just over two tons. The electronics were liquid-cooled (methanol/water mix), and nitrogen gas propelled the unit.

Of course, cooling is still a major issue in computing, as any enthusiast will tell you. At T-minus 15 seconds, Jack King (the voice of mission control) announced ‘guidance is internal ’, meaning, as NASA explains, ‘inertial and holds an orientation with respect to the stars’. In short, using three gyroscopes on an inertial platform. The IU computer system consisted of three subsystems: the Launch Vehicle Digital Computer (LVDC), the Launch Vehicle Data Adapter (LVDA), and the (analogue) flight computer, according to NASA’s official flight manual.

The LVDC hardware specification was:

• 28-bit word (Split into 2 x 13-bit plus 1-bit parity ‘syllables’)
• 2.048 MHz clock (I/O handled by LVDA via serial communication at 512Kbps)
• 32k x 28-bit words (RAM) magnetic core memory

At lift-off, the LVDC reported on 1,348 systems and transmitted back to mission control via a 51.2Kbps down-link using S-band (broadcasting at 2.4GHz which is now used in part for WiFi): the same speed as the last generation of analogue modems from the late nineties. Interestingly, Ryan notes the uplink speed was only 2.4Kbps, so ADSL broadband wasn't the first example of an asymmetric wide-area network connection!

In the same year the prototype Internet appeared (ARPANET), NASA was already using NASCOM (NASA Apollo Communication Network), which linked 16 receiver dishes around the world, from Europe to Australia, and even four ships in the Pacific and Atlantic. The central hub was the Goddard Space Flight Centre, northeast of Washington, DC. However, the most revolutionary development was the Apollo Guidance Computer (AGC).

The Apollo Guidance Computer

The AGC was fairly compact for a computer of its time and was one of the first to use integrated circuits. Each Apollo mission had two: one in the command module (CM) and one in the lunar excursion module (LEM). The primary system was called the PGNCS (Primary Guidance, Navigation and Control System, pronounced 'pings').

The LEM also housed a separate backup computer called the AGS (Abort Guidance System), which ran (open loop) in parallel with the primary AGC as a backup. The AGS's job was to abort the landing and get the LEM into a safe orbit where the two crew members could await rescue by their colleague (in the CM).

In NASA’s own words, ‘the invisibility of the AGS is a tribute to PGNCS, since the AGS was never needed to abort a landing. It was, however, an interesting and pioneering system in its own right’. Each AGC measured 61cm by 32cm by 15cm, about the size of the old ‘full tower’ form factor PC. It weighed 31.8kg and used around 70 watts of power, comparable to mid-nineties PCs.

The hardware specification was:

• 16-bit word (15 data bits and one parity bit)
• 1.024 MHz clock
• 16 I/O channels
• 36k x 16-bit words (ROM) magnetic core rope memory
• 2k x 16-bit words (RAM) magnetic core memory

The ‘core rope’ memory was a new development and boasted an incredible 2,000 bits per cubic inch, almost 20 times more compact than current core memory technology. Programmers threaded (or didn't thread) the individual ferrite cores onto the wires, all 598 thousand! Compare this specification to a typical PIC24 family microcontroller chip, which costs under £3, for which you get:

• 16-bit word
• 70 MHz clock (maximum)
• 31 I/O channels (6 A/D & 4 D/A)
• 256kB of addressable program memory
• 32KB of data memory

Operating at 3-3.6v and just milliwatts of power, measuring 4cm by 1cm by 0.5cm.

Development of the AGC

MIT designed the AGC in 1962, and Raytheon, a major U.S. defence contractor, built it. It was innovative because it was one of the first computers to use integrated circuit technology (which first appeared in 1958). Each used about 4,000 Fairchild ‘type-G’ (3-input NOR gate) circuits, or 24,000 transistors per computer. By today’s standards, this is nothing to shout about (high-performance processors now have billions of transistors). Still, compared to an IBM 7090 mainframe of the day, with about 50,000 transistors (and filling a room), that’s impressive.

For you

Be part of something bigger, join BCS, The Chartered Institute for IT.

In the summer of 1963, AGC prototypes reportedly consumed around 60% of the US supply of ICs. By 1965, AGC construction used 200,000 ICs, costing $20-$30 each. The computerhistory.org website suggests ‘this is one of the few cases in which NASA's requirements acted as a direct spur to the computer industry’. It was a big risk, though, and to minimise it, MIT decided to use only one type of IC for the whole design.

According to Paul Ceruzzi, this meant that ‘no Apollo Guidance Computer, on either the command or lunar modules, ever experienced a hardware failure during a mission.’

Eldon C. Hall, Lead Designer of the Apollo Guidance Computer, is credited with pushing for the use of ICs, despite much resistance from NASA’s own safety team. He realised that this was the only way to deliver a machine that was both powerful and compact enough for the mission. By the seventies, it was standard practice to build computers from discrete ICs and ultimately microprocessors - heralding the home computer revolution of the eighties and beyond.

The AGC user interface

The guidance computers would have been little use without a suitable user interface, in this case the DSKY (display and keyboard, pronounced 'diss-key'). The most interesting feature was how astronauts configured or programmed it during the mission. Limited memory meant they had to update it regularly during the mission. NASA estimates that ‘it took about 10,500 keystrokes to complete a lunar mission.’

Ramon Alonso, a computer scientist working on the AGC, championed the idea of using numerical ‘verbs’ and ‘nouns’ to make it easier to program. A verb would be a command such as 06, which means ‘display the information for the following (noun)’, and then the noun could be, for example, 44 or ‘orbit information’. This was clearly a hit with the astronauts: in an interview for the Hack the Moon website, Alonso recalls Dave Scott (Apollo 9 and 15) saying, ‘I don't know who thought up that verb and noun, but that was so good because we astronauts could really understand it’. How many user interfaces get such glowing reviews from the end users these days?

Lessons learned from the Apollo project

As with any advanced technology project, we learned a lot about project management and the development lifecycle. In NASA’s own review, one of the most important lessons was that software is more difficult to develop than hardware, reflecting that the choice of memory should be software-driven. Perhaps we take this for granted these days? They also noted that the software needed more modularisation, a core theme in any programming fundamentals course now.

Margaret Hamilton

The final observations come from computer science pioneer Margaret Hamilton, who worked on the AGC software at MIT. She is widely credited with inventing the term ‘software engineering’, as she explains, to bring the discipline the legitimacy and respect it deserved. In a presentation available on YouTube (2018), she looks back on the AGC project and the importance of developing real-time error recovery that provided a ‘program specific to system-wide protection’.

They developed a priority interrupt system for processors (pretty much standard these days) that let the highest-priority jobs keep running in the event of a problem. The infamous 1202 alarm Buzz Aldrin reported during lunar descent is an example of this. Fortunately, the software behaved as it should: ‘[the] software warned of a hardware problem AND compensated for it’. Testing, fault finding, bug fixing and patching are still as much of an issue now as they were back in the sixties, and Margaret laments in her presentation.

She gives a perfect example of how easy it is to miss something vital because of assumptions made about the design of test plans.

Her six-year-old daughter wanted to ‘play astronauts’ and crashed the simulator they were using for testing. It transpired she had triggered program P01 (the pre-launch program) during a simulated flight. However, this problem went unaddressed because ‘management’ assumed astronauts wouldn't do anything that silly. After the Apollo 8 astronauts triggered P01 during their flight (and spent hours resetting everything), the bug was fixed. Perhaps the lesson is: employ your kids to do the alpha testing.

Note: This article was updated with additional content written by Martin Cooper MBCS, on 12/10/2026.
