In mainstream literature, the very concept of enterprise architecture was always strongly associated, if not equated, with systems thinking. The reasons for this linkage are rather evident: modern enterprises represent complex socio-technical systems consisting of numerous interrelated business and IT components, or hierarchical systems of systems. ‘Enterprise architects often make a big deal about an enterprise being a system of systems, but, really, everything that we as enterprise architects are likely to think of as a system is likely to be a system of systems’, explained the late Len Fehskens, the chief editor of the Journal of Enterprise Architecture1 (page 12).
Systems thinking calls for attending to things in a holistic way, understanding mutual dependencies between various system elements and uncovering existing feedback loops in their dynamic behaviour. Unsurprisingly, systems thinking is praised by many EA gurus and academics. Some people claim that systems thinking ‘can be considered a basic principle of EA’2 (page 7), while others go even further and argue that ‘enterprise architecture is a way of using system thinking as an instrument to integrate and align all organisational levels’3 (page 5). It would be arguably fair to say that today, systems thinking represents one of the core paradigms occupying the mindset of EA practitioners, if not the single most prominent paradigm. And yet, is systems thinking actually so helpful for architects and EA practices?
Minor problem with systems thinking
One problem with systems thinking as a paradigm for EA practitioners, is its general triviality and inability to provide any actionable suggestions. On the one hand, since any rational thinking inevitably implies identifying various cause-and-effect relationships between relevant entities and these processes happen naturally and unconsciously in the human brain, almost all sane thinking is essentially systems thinking. It is hard to imagine a serious act of thinking that does not try to foresee and take into account possible organisational implications, ensuing consequences and side effects of the corresponding planning decisions. For this reason, ‘systems thinking’ is not much different from simply ‘thinking’, or at least from intelligent thinking, and unintelligent people rarely rise to positions of responsibility in organisations. Except for patently naïve judgements and sheer leaps of faith, systems thinking is a truism, largely ordinary thinking.
On the other hand, the entire systems thinking discourse has essentially nothing to show in terms of valuable recommendations for EA practitioners. For instance, an examination of popular books on systems thinking4, 5, 6 suggests, that these books are barely relevant to the daily activities of architects in organisations. These books are teeming with clever sounding, but practically meaningless notions (e.g. equifinality) and statements (e.g. the whole is greater than the sum of its parts) none of which arguably has any definite inferences or lessons for an EA practice. Even the specialised book of almost 500 pages long that promises to apply systems thinking in an EA practice7, in my opinion, fails to fulfil its promise. Despite that the topic of systems thinking is astonishingly popular within the EA community, any concrete explanations of how exactly advanced systems thinking helps architects can hardly be found (beyond intuitive common-sense ideas).
For the most part, systems thinking is nothing more than a mere glorification of holism, having no particular implications for architects, EA practices and organisations. Theoretically, it borders with pseudo-science, with the exception of apparent platitudes (e.g. all things are interrelated), having no real descriptive or prescriptive power. Like many other industry buzzwords (e.g. agile8), systems thinking sounds extremely attractive and is largely synonymous with good thinking. The virtue of systems thinking is hard to deny, even though this term remains mostly a cliché. For example, who would dare to argue against systems thinking and promote unsystematic, haphazard or chaotic thinking instead?
Major problem with systems thinking
Another and much more severe trouble with systems thinking, as a paradigm, is the very emphasis on ‘thinking’ which obscures the true nature of organisational inefficiencies, hides the root causes of disconnection between business and IT, masks the real challenges of achieving alignment and diverts architects from finding their practical solutions. The problem here is that thinking, by definition, represents an isolated private mental activity, whereas improving business and IT alignment in organisations always requires exerting collective efforts involving multiple actors and, thus, represents an inherently social activity. Specifically, at least two aspects of organisational reality undermine the productivity of any personal thinking exercises and decision-making attempts: incomplete knowledge and limited power. Each of these aspects alone is sufficient to minimise, if not nullify, the value of systems thinking for architects and EA practices.
On the one hand, no single person in an organisation is competent enough and possesses all the necessary knowledge for making optimal planning decisions. For example, C-level executives understand long-term business strategy; product managers - current customer needs; IT leaders - available technology capabilities; and software developers - down-to-earth implementation details. Hence, all decisions that relate to business and IT alignment should be contributed to by all the relevant parties with complementary expertise to ensure their overall efficacy, rather than be made by some lone architects or any other actors equipped with systems thinking. Even the most brilliant solitary systems thinkers cannot obtain, process and leverage all the pertinent information for effective decision-making - collective engagement is required.
On the other hand, no one in an organisation wields unlimited power and is capable of enforcing a successful execution of a decision that is resisted by other stakeholders, deemed unreasonable or neglects their essential concerns, let alone is poorly grasped by its implementers. Instead, all decisions should be understood, agreed and committed to by all the relevant parties. To put it simply, every idea of an individual actor has to be ‘sold’ to other significant actors in order to turn into a legitimate organisational decision and be acted upon. For this reason, best decisions in practice are those that reconcile and satisfy everyone’s interests, rather than those that look impeccable from architects’ point of view as chief systems thinkers. Even the most ‘theoretically’ perfect planning decisions from the systems thinking perspective will not be treated seriously unless they are accepted by all their stakeholders.
Due to the social, rather than mental, nature of decision-making processes in organisations, better business and IT alignment simply cannot be achieved by means of improving thinking, be it systems thinking or any other special sort of thinking, e.g. design thinking or architectural thinking. Architects’ private thinking, including systems thinking, is largely irrelevant to the actual alignment challenges faced by organisations as collectives of interacting people with diverse backgrounds, responsibilities and goals. Taking into account that systems thinking currently represents one of the foundational paradigms for EA practitioners, it should not be particularly surprising that many architects are perceived by their colleagues as lone visionaries, arcane denizens of ivory towers, idealistic builders of imaginable cloud castles, existing separately from the reality around them. Such architects more often get fired, than enact any positive organisational changes. At the same time, systems thinking on an enterprise-wide scale can be considered only as an unattainable ideal, which is desirable in principle, but unrealisable in practice, or as a ‘something that can be dreamed about’, but never enacted.
From systems thinking to communication
The analysis provided above demonstrates that systems thinking, as a personal mental disposition, besides being a trivial idea, is essentially orthogonal to the social problem of alignment. Aligning business and IT elements of organisations requires improving interpersonal information exchange between various stakeholders and establishing collaborative decision-making procedures, rather than merely thinking differently. For this reason, systems thinking on its own, no matter how well-developed, is unable to deliver any significant organisational enhancements (besides that, it is also debatable whether, or to what extent systems thinking can be developed in an individual). In other words, systems thinking as a paradigm for EA practitioners is mostly futile, it cannot really benefit EA practices and drive the EA discipline forward.
At the same time, achieving business and IT alignment in organisations clearly correlates with the goal of improving communication between various organisational actors. On the one hand, effective communication boosts information sharing which, in turn, allows making optimal planning decisions based on all the available information. On the other hand, effective communication facilitates open discussions of planning decisions, their critical evaluation, informed acceptance and group commitment to their execution. Thereby, communication addresses the limitations of both knowledge and power inherent to individual actors discussed earlier. Essentially, ideal communication between its employees turns an organisation into a single ‘big brain’ capable of making optimal planning decisions via collective intelligence, securing global commitment to their implementation and coordinating everyone’s efforts and activities.
Therefore, an EA practice is, first of all, a communication practice, rather than a systems thinking practice. From the practical perspective, it is communication, not thinking, that provides the key to solving organisational problems with business and IT alignment. In fact, most elements of an EA practice (e.g. processes, documents, tools, etc.) serve the purpose of enabling better communication. Although communication is a less popular, ‘unfashionable’ and largely unnoticed subject in the EA literature, the paradigm of communication actually offers some clear and actionable objectives for EA practitioners, that are likely to improve alignment in organisations.
Improving communication as a practical imperative
The imperative of enhancing communication between business and IT stakeholders yields numerous practical suggestions conducive to the quality of decision-making in an EA practice and, eventually, to business and IT alignment. Even though these suggestions are very diverse and cover various aspects of an EA practice, the three major target areas include EA-related processes, documents and governance procedures. The respective suggestions can be best formulated as questions, answers to which should be sought by architects, all of which can be clearly traced to the common goal of improving communication.
The first target area is decision-making processes related to enterprise architecture (see also Enterprise Architecture Practice on a Single Page). One should ask:
- With whom to communicate? Architects should identify and involve relevant stakeholders in decision-making processes.
- When to communicate? Architects should engage stakeholders at the right time moments, timely, typically early in the process.
- How to communicate? Architects should grope a common language suitable for communicating with different stakeholder groups.
- How to engage in communication? Architects should find the ways to ensure active stakeholder involvement, rather than merely their passive presence.
- How to communicate productively? Architects should develop constructive approaches for resolving conflicts between the stakeholders, alleviating contradictions and reaching closure on the final decisions.
Answers to these and similar questions should be continually sought by architects to maximise the added value of collaboration processes and thereby promote business and IT alignment.
The second target area is EA-related documents, or artifacts (see also Enterprise Architecture on a Single Page).
- What EA artifacts are necessary for communication? Architects should choose which EA artifacts to employ to underpin conversations and capture achieved agreements, i.e. which decisions EA artifacts to use.
- When to create EA artifacts for communication? Architects should decide at which phases of decision-making processes EA artifacts need to be initiated and finalised.
- How exactly to use EA artifacts for communication? Architects should find best approaches to leveraging EA artifacts for supporting joint decision-making.
- What information to include in EA artifacts for better communication? Architects should define the informational contents of EA artifacts to fully satisfy the information needs of their stakeholders.
- How to represent information in EA artifacts for effectual communication? Architects should determine the most efficient ways of packaging, structuring and visually presenting the information in EA artifacts to resonate with the thought processes of their audience.
Answers to these and similar questions should be constantly searched by architects to increase the practical utility of EA artifacts and thereby facilitate business and IT alignment.
The third target area is governance procedures related to enterprise architecture, i.e. formal endorsement and authorisation of EA-related decisions reflected in the respective EA artifacts.
- Whom should the proposed planning decisions be communicated to? Architects should identify pertinent senior managers capable of sanctioning and enforcing the execution of planning decisions.
- What information regarding the planning decisions should be communicated to senior decision-makers? Architects should extract the right, most essential information on the proposed decisions to be presented to decision-makers.
- How should the communication feedback be captured and handled? Architects should develop appropriate approaches for dealing with the reaction of decision-makers on the proposed planning decisions.
- How should the approved planning decisions be communicated to their implementers? Architects should find effective means of spreading the information on the authorised decisions and conveying these decisions to all relevant ‘downstream’ actors.
Answers to these and similar questions should be persistently looked for and perfected by architects to raise the efficiency of EA-related governance procedures and thereby strengthen business and IT alignment.
Although the list of questions provided above is far from being complete and exhaustive, it offers a number of basic suggestions for EA practitioners on what needs to be done to address the alignment problem in their organisations and outlines approximate courses of action to be taken on the way to improving business and IT alignment.
Moreover, the adoption of communication as the principal paradigm also influences many other aspects of our understanding of enterprise architecture and EA practices in organisations, e.g. theoretical basis, conceptualisation of the role of architects, metaphors for EA-related activities, their critical success factors, etc.
On fake and real tools (again)
Earlier, I reported that the EA community greatly suffers from the persistent confusion between ‘fake tools’ and ‘real tools’ for enterprise architecture. Fake tools (tools in a broader sense) represent concepts, approaches and techniques that enjoy a high standing in discourse, but bring little or no value in practice, e.g. Zachman, TOGAF and ArchiMate. On the contrary, real tools are rather weakly discussed and seldom spoken about, while they actually represent genuine working devices, e.g. business capability models, technology reference models and architecture debt.
Systems thinking, as a tool for enterprise architecture, evidently gravitates towards fake tools: it is often praised in EA-related publications and paid lip service to, but rarely, if ever, it is explained what its practical manifestations or consequences are. Like the highly acclaimed ‘ontology’ for enterprise architecture, systems thinking represents a perfect rhetorical instrument that pretends to be a sort of ‘theory’ of enterprise architecture, offers necessary pseudo-scientific obscurity, creates a false aura of wisdom and an illusory sense of profoundness. Unsurprisingly, systems thinking is arguably one of the most favourite topics in the presentations of esoteric EA gurus and ivory-tower university professors. However, besides being a convenient subject for endless speculations, systems thinking has no other merits: it is distant from the practical realities, provides no concrete suggestions for action whatsoever and ends up with empty declarations. Apart from obvious common-sense ideas, systems thinking relates to real-world EA practices in the same sense in which it does, for example, the famous 30-cells ‘ontology’, i.e. in no real sense.
By contrast, communication is certainly a real tool. Although being a largely neglected topic in literature, it is communication that shapes the meaning of most daily activities of architects and other participants of EA practices. Unlike the sterile idea of advancing systems thinking, the imperative of improving communication has a clearly traceable connection to the core objectives of an EA practice: effective communication leads to mutual understanding, collaboration and partnership between business and IT stakeholders and, ultimately, to business and IT alignment. The comparison of the paradigms of systems thinking and communication provided above is summarised in Figure 1.
The paradigm shift is required
Since mere mortals working in organisations have neither gigantic brains to know everything and plan all aspects of their companies alone, nor magic wands to miraculously materialise their grand designs, developing systems thinking, as a private mental propensity of individuals, is unable to help organisations improve business and IT alignment. For this reason, systems thinking represents a fruitless paradigm that cannot advance the EA discipline - a dead end. At best, it can be viewed as a ‘hygiene factor’ for rejecting inept architects incapable of thinking rationally, or as a prerequisite for entering a profession, but not as a major determinant of organisational success with enterprise architecture. At worst, systems thinking can be deemed harmful due to its tendency to disguise our lack of understanding of what successful EA practices actually require and substitute genuine knowledge with vague appeals for more holistic approaches. Analogously to useless EA frameworks, like TOGAF and Zachman, systems thinking only distracts our attention away from real questions and best practices.
In order to mature, the EA discipline needs to shift its dominant paradigm from systems thinking to communication, i.e. abandon the concept of systems thinking as bankrupt and adopt the idea of communication as the cornerstone of an EA practice instead. On the one hand, as an overarching paradigm, communication sets much more tangible goals for an EA practice as a whole and provides an incomparably clearer direction to individual EA practitioners than systems thinking. On the other hand, communication without systems thinking may lead to suboptimal planning, but systems thinking without communication can lead only to daydreaming and fantasising. In any case, imperfect plans that are agreed and acted upon triumph over splendidly thought-out systemic plans that end-up lying on shelves and collecting dust.
As it is evident from my studies of EA practices, organisations willing to improve their business and IT alignment should strive for more involving communication, instead of more systemic thinking. For all practical purposes, systems thinking, as something more than an obvious idea that systematic thinking is better than unsystematic one, can be safely forgotten - it is communication that should be improved. Put it simply, thinking will not help you improve business and IT alignment in your organisation, only communicating will.
About the author
Svyatoslav Kotusev is an independent researcher, educator and consultant. Since 2013 he focuses on studying enterprise architecture practices in organisations.
He is an author of the book ‘The Practice of Enterprise Architecture: A Modern Approach to Business and IT Alignment’ and many articles on enterprise architecture that appeared in various academic journals and conferences, industry magazines and online outlets.
Svyatoslav received his PhD in information systems from RMIT University, Melbourne, Australia. Prior to his research career he held various software development and architecture positions in industry.
1 Fehskens, L. (2015) ‘Book Review: Composite/Structured Design" by Glenford J. Myers’, Journal of Enterprise Architecture, Vol. 11, No. 3, pp. 12-15.
2 Simon, D., Fischbach, K., and Schoder, D. (2014) ‘Enterprise Architecture Management and Its Role in Corporate Strategic Management’, Information Systems and e-Business Management, Vol. 12, No. 1, pp. 5-42.
3 Ugwu, K. (2017) ‘Understanding the Complementary Relationship Between Enterprise Architecture & Project Management’, Architecture and Governance Magazine, Vol. 13, No. 2, pp. 3-6.
4 Weinberg, G.M. (2001) An Introduction to General Systems Thinking (Silver Anniversary Edition), New York, NY: Dorset House.
5 Meadows, D.H., and Wright, D. (2008) Thinking in Systems: A Primer, White River Junction, VT: Chelsea Green Publishing.
6 Gharajedaghi, J. (2011) Systems Thinking: Managing Chaos and Complexity (3rd Edition), Burlington, MA: Morgan Kaufmann.
7 Gotze, J., and Jensen-Waud, A. (eds.) (2013) Beyond Alignment: Applying Systems Thinking in Architecting Enterprises, London: College Publications.
8 Meyer, B. (2014) Agile!: The Good, the Hype and the Ugly, Zurich, Switzerland: Springer.
